The Seasonic PRIME TX-1300 1300W Titanium ATX 3.0 Fully Modular PSU is a high-end power supply unit (PSU) designed for enthusiast-grade gaming PCs, workstations, and power-hungry systems. It delivers 1300 watts of stable power, meeting 80 PLUS Titanium efficiency standards for maximum energy savings and performance.
Key Features:
🔹 1300W Power Output – Ideal for high-performance gaming rigs, overclocked systems, and workstations.
🔹 80 PLUS Titanium Certification – Industry-leading efficiency (94%+), reducing energy waste and heat.
🔹 ATX 3.0 & PCIe 5.0 Ready – Supports modern GPUs like NVIDIA RTX 40-series with native 12VHPWR (16-pin) cable.
🔹 Fully Modular Design – Only connect the cables you need, ensuring better cable management and airflow.
🔹 High-Quality Japanese Capacitors – Provides exceptional durability and reliability.
🔹 Premium Hybrid Fan Control – Ultra-quiet 135mm Fluid Dynamic Bearing (FDB) fan for silent operation.
🔹 Robust Protection Features – Over-voltage, over-power, over-temperature, and short-circuit protection.
🔹 12-Year Warranty – One of the longest warranties in the industry, ensuring long-term reliability.
Who Is It For?
✅ Gamers with high-end GPUs (RTX 4090, RX 7900 XTX, etc.)
✅ Overclockers pushing CPUs and GPUs to the limit
✅ Workstation users running multiple GPUs, AI workloads, or rendering
✅ PC builders looking for best-in-class efficiency, reliability, and quiet operation
FEATURE SUMMARY
- Super-High Efficiency, 80 PLUS® Platinum Certified
- Fully Modular
- ATX 3.0 and 16-Pin PCIe Gen 5 Cable (12VHPWR)
- Top-Quality 135 mm Fluid Dynamic Bearing Fan
- Premium Hybrid Fan Control
- Tight Voltage Regulation (12V, 5V and 3.3V) [± 3%]
- Gold Plated High Current Terminal (MB, CPU and PCIe)
| Technical Specifications |
| 80PLUS® |
Platinum |
| Cybenetics Efficiency Level |
TBA |
| Cybenetics Noise Level |
TBA |
| Form Factor |
Intel ATX 12V |
| Dimensions |
160 mm (L) x 150 mm (W) x 86 mm (H) |
| Fan Information |
Fan Size |
135 mm |
| Fan Control |
Premium Hybrid Fan Control |
| Fan Bearing |
Fluid Dynamic Bearing |
| Life Expectancy |
50,000 hours at 40 °C, 15 % - 65 % RH |
| Cable Information |
Modularity |
Fully Modular |
| Cable type |
Flat black cables |
| Electrical Features |
Operating Temperature |
0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan |
150,000 hours |
| AC Input |
Full Range |
| Protection |
OPP, OVP, UVP, OCP, OTP, SCP |
| Safety and Environmental |
Safety and EMC |
cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Environmental Compliance |
Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
| Warranty |
10 Years |
|
Power Output
|
| AC Input |
Voltage: 100 V - 240 V |
| Current: 15 - 7.5 A |
| Frequency: 50 Hz - 60 Hz |
| DC Output |
Rail |
+3.3 V |
+5 V |
+12 V |
-12 V |
+5 VSB |
| Maximum Power |
25 A |
25 A |
100 A |
0.3 A |
3 A |
| 125 W |
1200 W |
3.6 W |
15 W |
| Total Continuous Power |
1200 W |
